PlasmaConnect™

Compact oxidation system

PlasmaConnect™ is a modular, ready-to-use oxidation system for drinking water and wastewater treatment based on innovative C-ION™ technology. It uses non-thermal plasma (NTP) for advanced oxidation of water pollution using ionised air.

It is already being used successfully in wastewater and drinking water treatment as well as in water reuse applications. Thanks to its high efficiency, easy integration and broad effectiveness against a wide range of pollutants, C-ION™ sets new standards in modern water treatment.

The technology is based on the generation of reactive oxygen species (ROS) by dielectric barrier discharge (DBE) in ambient air – without the need for complex supply air treatment. These ROS have a high oxidation potential and enable the effective degradation of organic and inorganic pollutants. These include drug residues, hormones, pesticides, herbicides, dyes and humic substances, as well as metals such as iron, manganese and arsenic. The process also has a disinfecting effect.

The NTP is introduced into the water to be treated either through a submerged turbine or through external blowers and a floor-mounted aeration system (diffusers). The modular design allows existing plants to be retrofitted easily, regardless of plant size or application.

Applications

DRINKING WATER

  • For municipalities and water cooperatives
  • Iron, manganese and arsenic removal
  • Colour and humic substance removal

WASTEWATER & REUSE

  • Industrieabwasser: Vor- bzw. Nachbehandlung
  • Removal of anthropogenic trace substances as a fourth treatment stage in municipal sewage treatment plants
  • Optimisation of biological purification stages (reduction of bulking sludge)

Product Highlights & Advantages

  • Fully automatic operation with PLC control and touchscreen visualisation
  • Connection to building management system and remote maintenance possible
  • No supply air treatment or external cooling required
  • No continuous addition of chemicals necessary
  • Robust, low-maintenance system without precision mechanical components
  • Compact design with low space requirements
  • Significantly lower energy consumption compared to ozone and classic AOP processes
  • Modular, flexibly scalable and easy to retrofit
  • Ready for immediate use (plug & play), no start-up time
  • High oxidation potential through the formation of hydroxyl radicals (AOP)
  • Environmentally friendly: low energy consumption and no hazardous oxidation chemicals
  • Easy integration into existing infrastructure
  • Durable components, low maintenance

Technical data

Figures taken from the data sheets, 2026 version.

Base Unit Skid 5 Skid 5 Plus Skid 10
Plasma units 1 5 5, expandable to 10 10
Max. treatment capacity 5 m³/h 25 m³/h 25 m³/h, expanded 50 m³/h 50 m³/h raw water
Dimensions 710 x 180 x 125 mm 1,150 x 800 x 1,959 mm 1,170 x 791 x 1,940 mm 1,150 x 800 x 1,959 mm
Weight approx. 5.5 kg approx. 170 kg approx. 190 kg approx. 220 kg
Power supply 230 V / 50 Hz, 1-phase 400 V / 50 Hz, 3-phase 400 V / 50 Hz, 3-phase 400 V / 50 Hz, 3-phase
Connected load max. 0.1 kW incl. compressor 2.0 kW 2.0 kW 2.25 kW
Max. diffuser depth 1 m 2 m 2 m 2 m
Plasma outlet connection DN 20 DN 40 DN 40 DN 40
Plasma generation Dielectric barrier discharge (DBD), non-thermal (cold) plasma
Operating conditions 4 to 40 °C, air humidity below 70 %, air flow 20 to 120 l/min
Materials Housing PVC-U / PVDF, piping PVC-U and stainless steel 304/304L, frame stainless steel 304/304L

Frequently asked questions about PlasmaConnect

How does PlasmaConnect work?

PlasmaConnect uses non-thermal plasma, which is ionised air. The plasma is generated by a dielectric barrier discharge and drives advanced oxidation in the water.

Which substances can be removed?

The process removes persistent organic substances such as pharmaceutical residues, hormones, pesticides and herbicides. Inorganic substances such as iron, manganese and arsenic are oxidised. The process also disinfects and removes colour.

Which sizes are available?

The Base Unit treats up to 5 m³/h. Skid 5 handles up to 25 m³/h, Skid 5 Plus also 25 m³/h and can be expanded to 50 m³/h, and Skid 10 treats up to 50 m³/h of raw water.

How much power does the system need?

The Base Unit runs on 230 V / 50 Hz single phase and draws at most 0.1 kW including the compressor. The skids run on 400 V / 50 Hz three phase, Skid 5 at 2.0 kW and Skid 10 at 2.25 kW.

What are the requirements for air and temperature?

Temperature should be between 4 and 40 °C and air humidity below 70 percent. Air flow is between 20 and 120 litres per minute.

How deep can the diffuser be installed?

The Base Unit allows a diffuser depth of up to 1 metre, the skid versions up to 2 metres. The skids are supplied with disc diffusers measuring 12 inches x 70 mm.
